Battery Charger | Nanjing Top Power

TP4056

Technical datasheet, operating ranges, and workbench specifications for TP4056 manufactured by Nanjing Top Power.

No local component image available yet.

Complete Component Specifications

CategoryBattery Charger
ManufacturerNanjing Top Power
Voltage Min4.0
Voltage Max8.0
Logic Level5V
Pins8
InterfaceCC/CV
Form FactorESOP-8
Software SupportArduino/Linux
Current Draw1mA standby
