N-Channel MOSFET | STMicroelectronics

STP55NF06

Technical datasheet, operating ranges, and workbench specifications for STP55NF06 manufactured by STMicroelectronics.

STP55NF06 component photo

Complete Component Specifications

CategoryN-Channel MOSFET
ManufacturerSTMicroelectronics
Voltage Min0
Voltage Max60
Logic Level10V gate
Pins3
InterfacePWM
Form FactorTO-220
Software SupportN/A
Current Draw~1 mA gate drive
