Dual UART Expander | NXP
SC16IS752IPW
Technical datasheet, operating ranges, and workbench specifications for SC16IS752IPW manufactured by NXP.

Component image could not be loaded.
Complete Component Specifications
| Category | Dual UART Expander |
|---|---|
| Manufacturer | NXP |
| Voltage Min | 1.65 |
| Voltage Max | 3.6 |
| Logic Level | 1.8-3.3V |
| Pins | 28 |
| Interface | I2C/SPI/UART |
| Form Factor | TSSOP-28 |
| Software Support | Arduino/Linux |
| Current Draw | 2mA typical |
