LM7805

Technical datasheet, operating ranges, and workbench specifications for LM7805 manufactured by Texas Instruments.

No local component image available yet.

Complete Component Specifications

CategoryLinear Regulator
ManufacturerTexas Instruments
Voltage Min7
Voltage Max35
Logic LevelN/A
Pins3
InterfacePower
Form FactorTO-220
Software SupportN/A
Current Draw~5 mA quiescent
