Operational Amplifier | Texas Instruments
LM358P
Technical datasheet, operating ranges, and workbench specifications for LM358P manufactured by Texas Instruments.

Component image could not be loaded.
Complete Component Specifications
| Category | Operational Amplifier |
|---|---|
| Manufacturer | Texas Instruments |
| Voltage Min | 3.0 |
| Voltage Max | 32.0 |
| Logic Level | VCC Level |
| Pins | 8 |
| Interface | Dual Op-Amp |
| Form Factor | DIP-8 |
| Software Support | Analog / Hardware |
| Current Draw | 1mA quiescent |
Amazon links are affiliate links. As an Amazon Associate I earn from qualifying purchases.
Projects using this part
- Dark-Activated Night Light Beginner
- LM358 Line-Level Audio Preamp Intermediate
- LM358 Buffered Low-Pass Filter Intermediate
