N-Channel Power MOSFET | Infineon / International Rectifier

IRF540N

Technical datasheet, operating ranges, and workbench specifications for IRF540N manufactured by Infineon / International Rectifier.

IRF540N component photo

Complete Component Specifications

CategoryN-Channel Power MOSFET
ManufacturerInfineon / International Rectifier
Voltage Min2.0
Voltage Max100.0
Logic LevelGate: 10V
Pins3
InterfaceSwitching Gate
Form FactorTO-220
Software SupportHardware / PWM Control
Current DrawMicroamps leakage
