IRF520
Technical datasheet, operating ranges, and workbench specifications for IRF520 manufactured by Infineon.
Image could not be loaded.Image could not be loaded.Technical datasheet, operating ranges, and workbench specifications for IRF520 manufactured by Infineon.
Image could not be loaded.| Category | N-Channel MOSFET |
|---|---|
| Manufacturer | Infineon |
| Voltage Min | 0 |
| Voltage Max | 100 |
| Logic Level | 10V gate |
| Pins | 3 |
| Interface | PWM/GPIO |
| Form Factor | TO-220 |
| Software Support | Arduino with driver |
| Current Draw | ~1 mA gate charge |
These are unverified user contributions, separate from the manufacturer specifications above. Check the official datasheet before relying on technical advice.
