ESP8266-EX
Technical datasheet, operating ranges, and workbench specifications for ESP8266-EX manufactured by Espressif Systems.
Image could not be loaded.Image could not be loaded.Technical datasheet, operating ranges, and workbench specifications for ESP8266-EX manufactured by Espressif Systems.
Image could not be loaded.| Category | RF Transceiver / Wi-Fi |
|---|---|
| Manufacturer | Espressif Systems |
| Voltage Min | 3.0 |
| Voltage Max | 3.6 |
| Logic Level | 3.3V |
| Pins | 32 |
| Interface | Wi-Fi, SPI, UART, I2C |
| Form Factor | Module |
| Software Support | Arduino |
| Current Draw | 170mA active / 20µA sleep |
