Rotary Encoder | Alps Alpine
EC11E15244A5
Technical datasheet, operating ranges, and workbench specifications for EC11E15244A5 manufactured by Alps Alpine.

Component image could not be loaded.
Complete Component Specifications
| Category | Rotary Encoder |
|---|---|
| Manufacturer | Alps Alpine |
| Voltage Min | 0 |
| Voltage Max | 5 |
| Logic Level | N/A |
| Pins | 5 |
| Interface | Quadrature |
| Form Factor | Through-hole |
| Software Support | Arduino libraries |
| Current Draw | 10 mA |
