Rotary Encoder | Alps Alpine
EC11B15242B
Technical datasheet, operating ranges, and workbench specifications for EC11B15242B manufactured by Alps Alpine.
Image could not be loaded.Image could not be loaded.Technical datasheet, operating ranges, and workbench specifications for EC11B15242B manufactured by Alps Alpine.
Image could not be loaded.| Category | Rotary Encoder |
|---|---|
| Manufacturer | Alps Alpine |
| Voltage Min | 0 |
| Voltage Max | 5 |
| Logic Level | Digital |
| Pins | 5 |
| Interface | Quadrature |
| Form Factor | Panel/Shaft |
| Software Support | Arduino/ESP32 |
| Current Draw | ~1 mA signal |
