High Current Motor Driver | Infineon
BTS7960B
Technical datasheet, operating ranges, and workbench specifications for BTS7960B manufactured by Infineon.
Image could not be loaded.Image could not be loaded.Technical datasheet, operating ranges, and workbench specifications for BTS7960B manufactured by Infineon.
Image could not be loaded.| Category | High Current Motor Driver |
|---|---|
| Manufacturer | Infineon |
| Voltage Min | 5.5 |
| Voltage Max | 27.0 |
| Logic Level | 3.3-5V |
| Pins | 16 |
| Interface | PWM |
| Form Factor | TO-263-16 |
| Software Support | Arduino/Linux |
| Current Draw | 7uA sleep |
These are unverified user contributions, separate from the manufacturer specifications above. Check the official datasheet before relying on technical advice.
