Current Sensor | Allegro MicroSystems
ACS723LLCTR-20AB-T
Technical datasheet, operating ranges, and workbench specifications for ACS723LLCTR-20AB-T manufactured by Allegro MicroSystems.
No local component image available yet.
Complete Component Specifications
| Category | Current Sensor |
|---|---|
| Manufacturer | Allegro MicroSystems |
| Voltage Min | 4.5 |
| Voltage Max | 5.5 |
| Logic Level | Analog |
| Pins | 8 |
| Interface | Analog |
| Form Factor | SOIC-8 |
| Software Support | Arduino libraries |
| Current Draw | ~10 mA |
