Schottky Diode | onsemi

1N5819

Technical datasheet, operating ranges, and workbench specifications for 1N5819 manufactured by onsemi.

No local component image available yet.

Complete Component Specifications

CategorySchottky Diode
Manufactureronsemi
Voltage Min0
Voltage Max40
Logic LevelN/A
Pins2
InterfaceN/A
Form FactorDO-41
Software SupportN/A
Current Draw~1 mA test
